VLE-10 10k 2 Versymmetric® VLE 2-Post Lift
-
DESCRIPTION
Challenger adds the industry leading Versymmetric® Technology to the popular economy grade 10,000 lb 2-post lift, the LE10. Expand your service capabilities with the VLE10’s ability to lift a wide range of vehicles, including Forbes Top 20 Best-Selling Vehicles of 2020.
ALI® Certified
-
FEATURES + BENEFITS
- 3-Stage Versymmetric® front arms and 2-Stage rear arms provide a wide arm sweep for asymmetric and symmetric lifting in the same service bay.
- 11.875” standard height fits in service bays with 12’ ceiling height.
- Double telescoping screw pads with rubber foot pad.
- Padded overhead shut-off system prevents vehicle damage.
- A jacketed pulley-less single-point mechanical lock release system that was once exclusive to our CL series lifts is now standard on the VLE10.
- Rubber door guards protect the vehicle from door damage.
- Premium powder coat finish provides long-lasting durability.
- Plated arm restraints and arm pins inhibit rust and provide long-lasting durability.
-
SPECIFICATIONS
Model Number VLE10
Lifting Capacity 10,000 lbs. Lifting Configuration Versymmetric® Overall Height 11’ 11 ⁄ ” or 13’ 11” w/ ext LE2P10EH2 Overall Width 10’ 11 5/8” Drive Thru Clearance 8' 2 3/8"
Floor to Overhead Switch Standard 11’ 5”
Front Arm Reach Min. 22 5/16” Max. 39 3/8” Rear Arm Reach Min. 38 3/8” Max. 55 3/8" Screw Pad Height Min. 4 1/4" Max. 6 3/4" ALI® Certified Yes Color Red, Blue -
MANUAL + SPECS
Select Color
From $5,732.56
VLE-10 10k 2 Versymmetric® VLE 2-Post Lift—
$5,732.56
Description
-
DESCRIPTION
Challenger adds the industry leading Versymmetric® Technology to the popular economy grade 10,000 lb 2-post lift, the LE10. Expand your service capabilities with the VLE10’s ability to lift a wide range of vehicles, including Forbes Top 20 Best-Selling Vehicles of 2020.
ALI® Certified
-
FEATURES + BENEFITS
- 3-Stage Versymmetric® front arms and 2-Stage rear arms provide a wide arm sweep for asymmetric and symmetric lifting in the same service bay.
- 11.875” standard height fits in service bays with 12’ ceiling height.
- Double telescoping screw pads with rubber foot pad.
- Padded overhead shut-off system prevents vehicle damage.
- A jacketed pulley-less single-point mechanical lock release system that was once exclusive to our CL series lifts is now standard on the VLE10.
- Rubber door guards protect the vehicle from door damage.
- Premium powder coat finish provides long-lasting durability.
- Plated arm restraints and arm pins inhibit rust and provide long-lasting durability.
-
SPECIFICATIONS
Model Number VLE10
Lifting Capacity 10,000 lbs. Lifting Configuration Versymmetric® Overall Height 11’ 11 ⁄ ” or 13’ 11” w/ ext LE2P10EH2 Overall Width 10’ 11 5/8” Drive Thru Clearance 8' 2 3/8"
Floor to Overhead Switch Standard 11’ 5”
Front Arm Reach Min. 22 5/16” Max. 39 3/8” Rear Arm Reach Min. 38 3/8” Max. 55 3/8" Screw Pad Height Min. 4 1/4" Max. 6 3/4" ALI® Certified Yes Color Red, Blue -
MANUAL + SPECS
