DESCRIPTION
The FS-Curtis DLX60 Heatless Desiccant Air Dryer #DLX60 is engineered to deliver dependable, ultra-dry compressed air for industrial applications where performance and efficiency are critical. Designed for variable demand systems, the DLX60 provides consistent low dew point air while optimizing operating efficiency to help reduce long-term energy costs. Built on proven heatless desiccant drying technology and advanced system control, this dryer is ideal for manufacturing, automotive, and industrial environments that require reliable moisture removal and stable compressed air quality.
DLX Series Coda Controller with Automatic Sensatherm Energy Savings
DLX Series Coda Controller with Sensatherm automatically matches purge air use to the demand on the system. This ensures maximum performance, and the energy savings go right to your bottom line. The Coda Controller features a large, high-resolution touchscreen backed by a powerful microprocessor controller with robust communication capabilities for your IoT application.
-
FEATURES + BENEFITS
FS-Curtis DL desiccant dryers are available with three application-specific control systems. No matter what your application, there’s a control system just right for your needs. FS-Curtis DL heatless desiccant dryers deliver consistent outlet pressure dew points to -100˚F. By combining the proven benefits of desiccant drying technology with the industry-leading design, FS-Curtis’ DL dryers provide the most reliable compressed air drying system for various applications.
- Up-flow drying, which allows water and heavy contaminants to drop out of the air stream
- Premium grade desiccant beads enhance surface area, require minimum purge air, and have high crush strength
- ASME and CRN certified pressure vessels
- An optional pre-mounted filtration package increases the lifetime of the desiccant and avoids system contamination
- Precision switch valves automatically shift to the low -ressure side of the circuit to control process flow
-
SPECIFICATIONS
Model Number DLX60 Inlet Flow scfm 60 Standard Voltage 115/1/60 Maximum Operating Pressure 150 psig standard; (250 psig available,
please Alamo Equipment)Connections (in.) 1” NTP Dimensions 64" H x 34" W x 35" D Weight (lbs.) 445 Replacement Desiccant (lbs.) 80 Note: Replacement Desiccant: Premium Grade Activated Alumina AA-4, 1/8” Desiccant; weight is for two towers
